How To Remove Door Panel 1999-2004 Honda Odyssey
Created on: 2013-01-23
Watch this video to learn how to remove and replace the interior door panel on your 99-04 Honda Odyssey.
-
step 1 :Remove the door panel
- Remove two Phillips screws: one in the door pull and one behind the door latch.
- Remove the switch panel and unplug the wiring harness.
- Pull out the door latch and unclip the lock rod.
- Use a flat blade screwdriver to pry out the triangle panel.
- Pull the door panel up and off, using a putty knife and cloth to unclip it.
- Unplug the speaker.
- Carefully remove the water shield
-
step 2 :Install the door panel
- Replace the water shield
- Plug the speaker back in.
- Clip the door panel back on, threading through the wiring harness.
- Replace the triangular mirror panel.
- Replace the door latch, clipping together the locking rod.
- Plug the switch panel back in and clip it back into place.
- Screw in the two Phillips screws, one in the door pull and the other behind the door latch.
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
Brought to you by www.1AAuto.com your source for quality replacement parts and the best service on the internet.
Hi I'm Mike from 1A Auto, I hope this how to video helps you out, and next time you need parts for your vehicle think of 1AAuto.com. Thanks.
In this video we are going to show you how to remove and reinstall a front door panel on this 2003 Honda Odyssey, same as a 99-04 Odyssey. We do the driver's side; passenger side is the same procedure. The only tools you will need are a small flat blade screwdriver and a Philips screwdriver.
Start with a small screwdriver and if you look into this cup here, there's a little trap door to pry up and you can see a Philips screw there. Then there would be another trap door here but it is missing on this vehicle, but there's a Philips screw there. Remove these 2 Philips screws. Pull up, then back on this and pull it out. There are 2 connectors. They both have little tabs right in the middle tap on this blue one, press it down and this brown one press down pull it out. The door handle pulls forward and out and again there is a clip here on a run. Just push that clip with your finger or screwdriver. Just push that clip around, pull the rod up and out, and there's a connector here pull that off. Small screw right up here pull this out a little bit, work the screwdriver underneath pry it out, pull that up, grab the bottom. Work your finger underneath, pull firmly and release the clips. They are probably not going to release the clips if your door panel has never been off it maybe a little more difficult to release, but release those clips but lift your door panel up and off. Then your speaker is connected down here, the tab there are two tabs on each side squeeze the connector and pull it off.
Okay install, plug the speaker back in. Make sure your door is unlocked put this right back up, push the lockout, get the lock button started in there, and push it against the window seal and down. Make sure you lock it against the window there and reactivate all those tabs. Okay put this with the little tab at the bottom back in and down. Your door handle, reconnect your door lock if you have it. Pull this rod out and put it down in, flip the clip around to lock it on. Everything goes in, slide it back and this connect the blue clip, back brown clip put the front in first slid it down in. Put the screws back on.
We hope this helps you out brought to you by www.1AAuto.com your source for quality replacement parts and the best service on the internet. Please feel free to call us toll free: 888-844-3393 we're the company that's here for you on the internet and in person.
