Hey, friends. It's Len here from 1A Auto. Today we're gonna be working on our 2006 Toyota 4Runner, and I want to show you how to remove and install your cabin air filter. Let's get right into it. We're gonna go right behind the glovebox here. Hopefully, nothing too crazy falls out of here. This looks clean. So that's nice. Squeeze like this, and you're gonna see a little tab right here. That needs to pull out. Same thing over here.

And then, I just grab along this piston right and slide it off of this piece right there. At this point, you can look inside. You can see this rectangle coming across. Just gonna grab this end. Give a little tug, this end. Oh, yeah, I'd say it's about time. Let's bring this over to the trash receptacle, clean it out, and then we'll install our new one. Okay, so to install our new filter we're just gonna go in just like this. Slide it in.

All right, so now it looks like it's in but it's not. Right along here you're gonna notice little triangles with a cut out at the bottom and that's to hold the filter in. So, you just need to make sure you that you squish the filter down enough, so it gets under that lip. Should slide right in. Around here do the same on this side. That one looks good. Come right here. Here we go, awesome. Now when we install this you want to make sure these fins are facing up.

So that way the air... As the air is getting drawn into the vehicle it's coming down here, and it's gonna accumulate inside all these ridges. This is gonna help protect you from breathing in all that crud that you saw on the old one. I'll come down here. Line it up with the hole, and just slide it in. We're gonna listen for a click noise, awesome. Give it a nice little tug. Try to wiggle it around. It's definitely latched in, perfect.

At this point, I'm gonna lift this up. We're gonna pay attention to our piston now. You've got your little piton right there, okay? Right where my finger is, and on the piston there's a little hole. It's kinda like this one up here, except it's right down here, all right? So just lift up your box. So you get so the two are lined up. The hole with the piton. Slide it in. Here we go. Lift this up. This is gonna go up and over that just like that. Bonk, bonk, boom. Perfect, that looks great. Down the road you go.

Thanks for watching. Visit 1aauto.com. Your place for DIY auto repairs, for great parts, great service, and more content.

Hi, I’m Mike from 1A Auto. We’ve been selling auto parts for over 30 years!

Open the glove box. Pop the side cover off. Put that aside. Lift this up. Take this little damper string off. Push the glove box side in. Pop it off. Do the same for the other side. Just pull it in. The glove box will lower down.

To remove this screw and clip, use a Phillips head screwdriver. Loosen it. Pull its clip out. Put that aside. Push in on the tab on this side and then the glove box will come right out. Take out this upper compartment. This just lets you see down inside what you're doing, so just kind of lift it up, pull it straight out, and put that down aside.

The cabin air filter is back behind here, but just to let you look down inside because we need to remove this access panel here, so there's one, two, three, four screw clips. Use a Phillips head screwdriver to loosen these. There's a fifth one over here. Reach in here. Pull out. Push it back. Pull it out. I can see the bottom. There's two tabs. Push these up and on the top there's two tabs.

You're going to take your two hands with your thumb and index finger and reach up in here and squeeze them together and then pull that out. I'm going to carefully pull this out because this one is really dirty and filled with junk. Might never have been changed. Oops, my finger's stuck in there. I'm going to try to slide it out without dumping it into my blower motor. Wow, that is nearly clogged. This might not even been This probably smelled really bad and probably had very poor air flow through the heater and A/C. That is one of the worst I've seen.

Here's the cabin filter we pulled from our vehicle. It is completely clogged and filled with dirt. There's no way that any air is getting through this. It probably smells awful. This potentially could be original to the car. These should be changed every year or 12,000 miles. As you can see, this is a brand new one from 1aauto.com. It's the same exact style and size and design. This will fit in the tray. I'm going to pull this old one out over the trash brown, throw it away, and then we'll slide the new one in place. It'll fit great and work way better than this old one.

I'm just going to take a rag I've dampened with some glass cleaner. You could use water, anything, just to clean up some of the dust that's in here. There is a direction of flow marked on the air filter. The arrow is pointing down so the air comes in and goes into the blower motor, so we want that arrow pointing down. This will just slide into place, again, pretty flexible and gently push it down and in. Goes under these little tabs here and under this tab on this side. Should be one in the middle there. That's our brand new cabin air filter ready to be reinstalled.

Slide this tray back into place and then just push it right in. It does have an arrow pointing up. Now it's locked in place. Reinstall this cover. One of these clips was broken off, but there's three clips, so push up into place. Reinstall the threaded clips. Put this one over here. They'll just kind of push into place. Line them up. Push them as far as they'll go and then you can screw them back in. Just repeat this for all of them. Push it in. Put the glove box back in place. There's an opening here and a pin here. It's going to sit on that pin and slide this one up into place and then we'll push it up on the pins.

Before you forget, install the upper little cargo pocket. So it does say up. Now we go towards the top part. It just slides in place and clips in. Reinstall the clip on this side. You might have to move this around or adjust the clip out. Just thread it out. Just catch the top thread so it can squeeze together. Get it in place. I'll get that pushed in. Then put the center in, just like that. Hook up the little damper rope. Reinstall the side cover. Push it just beyond that trim there, get that clipped in. The cabin filter is replaced.
