In this video, we're going to show how to replace a spark plug on the 1998 Honda Civic with the 1.6 liter 4-cylinder engine and it's the same part and process on these vehicles from 1992 to 2000. The items you'll need for this is new spark plugs from 1AAuto.com, 5/8 inch spark plug socket and racket with an extension and a gap tool. Start off by disconnecting a spark plug wire and using a 5/8 inch spark plug socket, twist out that spark plug. If you're using a spark plug socket, the spark plug will come right up and out with the socket, otherwise you may need a magnet to pull it out.

SUp front is the old spark plug, behind it is the new one from 1A Auto, you can see that they're identical and they are going to mount exactly the same. Bring your new spark plug in, you want to make sure the gap's right so using a gap tool you want to pry that to the right size and for this vehicle it's supposed to be .044. Put the spark plug into the socket and lower down into place and just twist in and tighten it. In general, you want to torque spark plugs to about 20 to 25 per pounds. Once you have it tightened up then replace the wire and repeat for the other three.

We hope this video helps you out. Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet, please feel free to call us toll-free 888-844-3393. We're the company that's here for you on the internet and in person. Thank you.

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet.

Hi I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video, we're going to show you how to replace the spark plugs on this '03 Honda Odyssey, pretty much the same as any '99 to '04 Odyssey. Usual recommended changing for plugs is 50,000 miles or 100,000 miles if you have platinum tip plugs. Tools you'll need are a 10mm socket with a ratchet and extension, a flat blade screwdriver, a T40 Torx driver, a 5/8 spark plug socket and extension, and then a spark plug gap tool.

Okay, 10mm socket and I have an extension. One of these anyways it kind of goes down in there, but there are four bolts that hold the engine cover on here. Now you need a flat blade screw driver, and there are basically two little clips, turn them a quarter of a turn counter clockwise. Now, just make sure that they come out. There's another plug up on the end here that you have to pull up just firmly and pull that out. Now I'm looking at it from the passenger side, and you can see the coils right down here, one, two, three. Then the rears, there's actually there's no cover and you can see the tops of the coil, one here, two and three. Plenty of room to reach back in there and take them out.

Okay, first thing, each one has a harness and then just a little tab that you press in and disconnect the harness. I'm just going to do one to show you. I'm using a T40 Torx bit and a socket. Lower it down in here and just loosen this bolt up. Remove it. Grab your coil, shake up and down a little bit and pull it right out. Okay, to remove a spark plug, you're going to want a 5/8 spark plug socket and an extension. Put the socket and extension down in. Then you pull out the socket. If the spark plug socket is working well, it brings the spark plug right with it. Okay, the plug looks like they were replaced relatively recently, so I'm not going to put a new one in. I'm just going to kind of show you.
Usually, these plugs come gapped, but you want to check. This spark plug gap tool, according to the manual, plugs on this should be at .040, so you take your tool at .040 and run it through the gap, and you should be able to go in and out with just a little bit of resistance. Okay, so it's correctly gapped. You want to be careful when you're gapping. You can damage tips, but once you've gapped, reverse the procedure put the plug down in. You want to make sure you're holding the extension nice and centered in the hole, so you start the plug-in well and you don't cross thread it.

Tighten these to about between 10 and 15 foot pound, so I take the small wrench. Tighten them until you give them about 1/8 of a turn of tightness. You don't want to over-tightening them, you can damage your cylinder head so you don't want to do that, and under-tightening them can cause your engine to lose power. Okay, your coil from 1A Auto, it's an exact replacement. Then putting that on, you'll feel some resistance. Just push it down on firmly. Put your screw in. Start it with your fingers, and your T40 bit back in. Tighten on there firm, not too tight though. Reconnect and repeat for the other cylinders. Okay, now you bring this down. You kind of put your thumb on here so you can see that go right in, see these plugs go right in. Push it down on. Push that into place. Turn these a quarter of a turn clockwise and your cover back in place. I'll spare you some of this, just tightening up those bolts. I basically just kind of put them in by hand first, make sure they're going in correctly and then just tighten them up firm. You don't have to have them that tight at all. You should be all set.

We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the internet. Please feel free to call us toll free, 888-844-3393. We're the company that's here for you on the internet and in person.

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.

Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video, we'll show you how to replace the spark plugs on this 2008 Dodge Caliber with a 2 liter engine. The items you'll need for this are new spark plugs for 1AAuto.com, a T30 Torx bit and ratchet, 5/8 inch spark plug socket, and a gap tool.

Located right here, are your four ignition coils, under each one is your spark plugs. If you want to start off, just disconnect this harness, push the tab and pull it off. Right here, there's a T30 torx bolt, just go ahead and remove that. Once the bolt's removed, the ignition coil pulls right out. Using a ratchet, an extension, and a 5/8 inch spark plug socket, just remove that spark plug, and it pulls right out. If you don't have a spark plug socket, it's just a 5/8 inch socket then you can just use a stick magnet to remove that spark plug.

On the left is the old one. On the right is a new spark plug from 1A Auto. You can see they're identical, and they'll mount and fit exactly the same. You want to use your gap tool to make sure the gap on the spark plug is right. You want just a little bit of resistance. For this vehicle we want .05, and it's right where it is. It's good to go. Now put the spark plug into the socket, and then lower it down into place and tighten that up. We're going to just fast forward as Don does this. Next, lower your ignition coil down into place and replace that T30 Torx bolt, and then, tighten that up. Then, you want to tighten these between 15 and 20 foot-pounds. and repeat the process for all of the spark plugs. Reconnect each harness and you're all set.
