Hi, everyone. Sue here from 1A Auto, and today on our '06 Honda Element, I'm gonna show you how to replace a lower control arm. If you need this part or any other part for your car, click on the link below and head on over to 1aauto.com.

To remove the tire, you need a 19 millimeter socket. The vehicle has weight on it so that I can loosen up each lug nut as I go around. I'm using a two post lift. At home, you can use jack and jack stands. Now that I have it up in the air, I'm just gonna remove all the lug nuts. Beautiful. You can discard the hubcap. 14 millimeter wrench and a number five Allen socket. I'm going to put the 14 wrench on the sway bar link nut. I'm gonna install the Allen head in the stud with the cutout and we're gonna loosen up. You get yourself a good spot and you feel like a ratchet wrench is gonna work, then you can move onto that. You can take the Allen head socket off, and you should be able to get this right off. I'm gonna take a pry bar and see if I can pull that right out of the cutout. There we go. Nice. So I'm gonna remove the cotter pin and discard that, and I'm gonna take the castle nut off. That's a 17 millimeter socket.

I'm gonna slide that right on there and break it free. Discard that. Now I'm gonna use a pickle fork to break the ball joint free from the control arm, and if you're not replacing your ball joint and you're gonna reuse the ball joint, you've got to be really careful and not to tear this boot on the ball joint. Luckily for me, this boot's already torn. So I don't have to worry about trying to save it. But if your boot is in good shape and your ball joint's in good shape, just be careful.

Work your pickle fork underneath the boot and not pinching the boot. There it is. So now I can separate my control arm from the ball joint spindle and just pull down like that and push that knuckle out of the way. Remove the two control arm bolts. Take a 19 millimeter socket. As you can see, the CV shaft has been dismounted from the knuckle. It doesn't need to be if you're just doing the lower control arm. We're also doing a ball joint. Sweet. I'm gonna take a look at both bolts. Okay, they're the same length, same shanks, same diameter, so you don't have to separate them. I'm just gonna pull this control arm out. Just rock it back and forth.

Here we have the new lower control arm for our '06 Element from 1A Auto and here we have the one that we just took out. They're identical in shape and size. The 1A Auto comes with pressed in bushings for both control arm marks where it hits the sub-frame. It's got the ear for the sway bar link and the nice, thick cast for the ball joint. If you need this part or any other part for your car, click on the link below and head on over to 1aauto.com.

I'm gonna line up the front bolt first, and I'm gonna actually thread a bolt in so I'm not fighting with that. Just want to turn it a couple of threads by hand. Then I'm gonna bring the backside up in there. That's why I wanted the front bolted in, because this is gonna take some pressure. There we go. There we go. How does it look? There we go. Perfect.

Now that we've snugged them down, we're gonna torque it to the manufacturer's spec, which is 61 foot-pounds. What I'm gonna do, is I like to make sure it's seated in there. Now I'm gonna put the new castle nut. The new castle nut is an 18 millimeter socket and we're going the wrong way. There we go. I'm gonna snug this up, pull that ball joint spindle right down through. Once I feel that snugging, the torque is 51 foot-pounds. I'm gonna torque it up. Now let's see if the cotter pin has any line up holes and it's fine. Yup, I can put the new cotter pin in.

I like to put the cotter pin so that the opening is on the inside there so that way when I bend it down and lock it into place, I can cut it easily and it won't cut people that are just doing simple oil changes or anything like that—any front end or brakes. Sometimes, these cotter pins can be more dangerous than they appear, and then I'll fold that up. So I'm gonna take a pry bar, and I'm going to slide it up through here so that I can lift that up and line up the sway bar. Beautiful. Put the new nut on. As you can see, we ended up replacing the sway bar link. So there's no Allen head on the end of the new one. Instead, it's a 14 millimeter on the inside and a 15 on the nut side. I'm gonna tighten this down. So now we're gonna torque the nut to 29 foot-pounds.

Gonna mount the tire again, and the reason why I put the tire on before I tighten the top of the strut is because I want the weight of the weight on the suspension to assure that I'm not pulling up on that cap, the strut cap and that can warp the studs on the outer edge. I want the vehicle weight down holding that up and then I can get a true torque end tightening of it.

Grab your hubcap because this particular Honda does not have extra Y cutouts for three lug nuts. Set the rim up on the hub and put your lug nuts on. So the wheel torque, now that I got the weight of the vehicle down on the tire and I'm gonna torque up the wheels and the wheel torque. Spec is 80 foot-pounds.
